The host subsystem¶

otto.host is the largest package: it turns a lab-data entry into a live object you can run commands on, move files to, elevate privileges on, and power-cycle — over SSH, Telnet, a serial console, or docker exec.

Class hierarchy¶

The concrete host classes and every base between them and BaseHost — generated from the live classes at build time, so this diagram tracks the code (each node links to its API page):

What each layer adds:

LocalHost exists so instructions can mix local build steps with remote deployment through one interface; every lab gets a built-in local host, excluded from fleet iteration by default (The command lifecycle). DockerContainerHost delegates everything to a parent UnixHost rather than duplicating the transport stack — that design has its own page: Design: Docker container hosts.

Sessions: persistent run vs stateless oneshot¶

run() executes on the host’s persistent shell session (HostSession): working directory, environment, and elevation state survive across calls, and the session’s expect/send primitives are available for interactive flows. Named sessions can be opened explicitly (open_session) for parallel stateful streams.

oneshot() runs each call independently of the persistent session and of other concurrent oneshot calls, which is what makes asyncio.gather() fan-out safe. Embedded hosts are oneshot-only — a serial console has no multiplexed channels to hold a session on.

Two pieces of per-session state matter architecturally:

• current_user and elevation. Privilege changes (su, sudo, switch_user) are session state, tracked per session rather than per host — two sessions on one host can run as different users. The host’s current_user property reports its default session’s effective user.

• Command framing. How a command is wrapped, echoed, and its completion detected is a shell-dialect concern, factored into CommandFrame — a small stateless value object the session holds rather than is (BashFrame for POSIX shells, ZephyrFrame for the Zephyr shell). Per-session sentinels are passed in as values, keeping frames pure and unit-testable without a live session.

Connections, terms, and hops¶

ConnectionManager owns a host’s network resources and builds them lazily — constructing a host object opens nothing; the first verb that needs a connection does. The term (interactive transport: ssh or telnet) is pluggable through the TERM_BACKENDS registry, with TermContext — a frozen dataclass of construction inputs — as the public seam a custom backend implements against.

Hops are first-class: a host whose hop field names another lab host is reached by tunneling through that host’s SSH connection (HopTransport), and hops chain for multi-hop paths. The hop chain lives below the term/transfer layer, so every backend — including file transfers and netcat streams — works through hops without special-casing.

File transfer and capability resolution¶

All transfer backends live in otto.host.transfer, one class per selector, sharing BaseFileTransfer. Each backend declares which host_families it serves (sftp/scp/ftp/nc for Unix hosts; console/tftp for embedded targets).

Which backend a host actually uses is resolved from three inputs:

1. The host’s menu — valid_transfers / valid_terms in lab data declare what the machine supports.

2. Preferences — [host_preferences] tables (from lab data and product repos) rank capabilities per host selector; the first preference present in the menu wins, and product preferences take precedence over lab preferences.

3. Per-invocation overrides — --transfer / --term on the CLI, or keyword overrides on get_host(), have the final word.

The same mechanism resolves per-protocol option tables (e.g. ssh_options), so “prefer netcat on this board family, with these ports” is data, not code. See Host configuration (hosts.json) for the user-facing rules.

From lab data to a host object¶

Host construction is a boundary crossing, described fully in Data at the boundary. In brief: the os_type field selects an OsProfile — a named bundle of field defaults over a base family (unix, embedded) — the profile picks the host class and its pydantic spec, defaults and host fields are merged (host fields win), the spec validates, and to_host() builds the runtime object. Custom host classes and profiles register through register_host_class / register_os_profile (OS Profiles & Custom Host Classes).

Profiles are the data half of otto’s customization split: they name a bundle of defaults many hosts share. The code half is products — Product bundles stage/install/uninstall behavior, and product repos attach products to hosts by registering a provider function (register_product_provider) that otto applies to each host at ingest. Declaring products in lab data is deliberately not supported: lab data stays product-agnostic and the two evolve independently.

Embedded strategies¶

Embedded hosts compose three more stateless strategy objects, each with its own registry (Registries and the pluggable CLI):

• CommandFrame — the shell dialect.

• BinaryLoader — how a binary payload gets onto the target and verified (llext-hex drives Zephyr’s LLEXT loader over the console).

• EmbeddedFileSystem — what on-device filesystem (if any) transfers and file ops may assume: FAT on a RAM disk, LittleFS, or none, with graceful degradation.

Power control (PowerController) and privilege escalation (otto.host.privilege) follow the same pattern: an abstract strategy, a registry, and per-host selection from lab data.
